The KryonEngine

The Open-sourced Magnetic Free Energy Device



The KryonEngine is a mechanical device which generates the Earth's first (heretofore undisclosed and taught/believed to be impossible) real Perpetual movement (French: "Mouvement perpétuel", German/Latin: "Perpetuum mobile") thanks to an intelligent arrangement of magnets, such as permanent magnets or electromagnets.

It is the first device publicly disclosed to mankind to produce free, unlimited and clean energy, by arranging

  • a 1st set of stationary dipole magnets arranged in a circle, rotating around their respective geometric center axis, and
  • a 2nd set of dipole magnets rotating (a) around their respective geometric center axis at twice the speed of the magnets of the 1st set and in the opposite direction, and rotating (b) as an ensemble in a circle formation around the circle's center axis, whereby each magnet passes consecutively next to each of the magnets of the 1st set,

in such a way that the magnets of the 1st set first attract and then repulse any given magnet of the 2nd set, and vice versa, resulting in a continuous perpetual circular movement for each one of all magnets involved as well as for the ensemble of magnets in the circle formation.

The appropriate Coils (or complete Electric generators) can be integrated with any of the rotating magnets or elements in order to convert the kinetic energy generated by the magnetic push-and-pull forces into electricity by applying Faraday's Law of Induction.

Configuration examples

The below examples show the top views of possible configurations of a KryonEngine.

Note (regarding the below illustrations):

  • For the purpose of improved readability, bar magnets are shown instead of diametrically magnetized ring/disc magnets (whose outlines are indicated by the dashed lines).
  • Proportions are not actual.

Example 1

Download all frames of this animation (.zip)

Example 2 (preferred)

  • This example shows a KryonEngine configuration featuring 1 Wheel linking 4 Wheelmagnets, and 16 KryonGates having 2 Gatemagnets each (optionally: only 1 Gatemagnet per KryonGate).
  • Unlike in Example 1, only half of all KryonGates are located in the x-y plane (magnets in pale color), the other half of the KryonGates being oriented along the z-axis (magnets in full color) and thus only show their top Gatemagnets (the ones below are hidden in this top view).
  • A cross-section through the Wheel would reveal the resulting "+ configuration" obtained by superimposing the orientations of the consecutive KryonGates. These rotationally offset KryonGates cancel out a "speed bump" which - depending on the chosen proportions of a given build - may occur around Position 0, due to a slightly increasing (respectively decreasing) value of the spatial Distance D. Download and use this spreadsheet model (.zip) to understand how the value of the spatial Distance D behaves.
  • Ideally, all KryonGates would additionally be "rotated" 45 degrees around their respective center axis (tangent to the Wheel's ring), such that the "+ configuration" obtained by superimposing the orientations of the consecutive KryonGates becomes a "x configuration" (which then results in perfectly symmetric magnetic forces). See the illustration: Wheel cross-sections.
  • Proportions are not actual: For the given magnet size, this example would require approximately double the radius shown (as a result of the behavior of the Distance D).

Download all frames of this animation (.zip)

Description

A mechanical build of a KryonEngine generally consists of

  • at least one circular Wheel consisting of several spokes connecting a peripheral ring to its center axle and rotating around its geometric center axis;
  • one ore more Wheelmagnets (dipole magnets such as bar magnets but ideally: diametrically magnetized ring/disc magnets) whose respective geometric center axis are tangent to the circle described by the Wheel's ring and equal to their respective rotational axis around which they rotate at equal speeds in such a way that their respective North and South poles’ resulting spatial trajectory describes a (potentially irregular) circular and closed double-helix that is twisted around the circle which is defined by the Wheel’s ring (this double-helix movement can be induced by guiding one or two given points of the Wheelmagnet’s periphery with one or two rails whose trajectory describe a helix respectively a double-helix twisted around the circle which is defined by the Wheel’s ring); a Secondary Wheelmagnet with identical properties, positioned behind the first Wheelmagnet adjacently or slightly distanced, at a relative rotational angle defined by the relative distance (to the first Wheelmagnet) applied to the given geometry of the double-helix may additionally support the movement through the KryonGates by adding to the obtained forward momentum of the Wheelmagnets an additional force of attraction respectively repulsion;
  • one ore more stationary KryonGates (definition: see below) through which the Wheelmagnets pass and which are arranged in a circle. Note: KryonGates do not have to be situated in the x-y plane, as shown in Example 1: As shown in Example 2, they can also be "rotated" 90 degrees around their respective center axis (tangent to the Wheel's ring) in order to be oriented along the z-axis (respectively 45 degrees in order to obtain a diagonal position);
  • one or more electric generators which can be connected to the Wheel's axle or be obtained by applying the appropriate coils to any of the rotating magnets involved, thus converting the generated kinetic energy into electricity by applying Faraday's Law of Induction.

A KryonGate consists of one or two stationary Gatemagnets. Gatemagnets are dipole magnets (such as bar magnets but ideally: diametrically magnetized ring/disc magnets) that

  • are located in planes that intersect at and with the Wheel’s center axis; if they belong to the same KryonGate, then they share the same plane and their geometric center axis are parallel to each other and positioned equidistantly on the periphery of a circle whose center axis is tangent to the circle defined by the Wheel’s ring and whose radius’ length is equal to the minimum distance that allows for the moving Wheelmagnets to pass without collision or friction;
  • rotate around their respective geometric center axis, in the same direction which corresponds to the opposite direction of the rotation of the Wheelmagnets, at equal speeds which correspond to precisely half the speed of the rotation of Wheelmagnets, a proportion which can be ensured by applying the appropriate coupling mechanism to the rotational movement of the Wheel (and thus its Wheelmagnets) and the rotational movement of the Gatemagnets;
  • have their respective rotational positions calibrated (via the above mentioned coupling mechanism) to those of passing Wheelmagnets, at the moment they all share the same plane, such that the straight line passing through all magnetic poles of the given Gatemagnets has a 90 degree angle relative to the line defined by the magnetic poles of the passing Wheelmagnet;
  • attract their closest respective Wheelmagnets that are moving towards them and repulse their closest respective Wheelmagnets that are moving away from them, resulting in a combination of push and pull forces which propel all Wheelmagnets in the forward direction and thus induce the rotational movement of the Wheel.

The movement of a Wheelmagnet through a KryonGate (which in this case is composed of 2 Gatemagnets) can be described by the sequence of its 5 key positions, as depicted by the 5 illustrations shown below (each showing both the top view and the front view):

Note (regarding the below illustrations):

  • For the purpose of improved readability, bar magnets are shown instead of diametrically magnetized ring/disc magnets (whose outlines are indicated by the dashed lines).
  • The proportions and distances between the 5 key positions in an actual build must be chosen such that - throughout the entire movement - the spatial Distance D between the attracting (respectively repulsing) magnetic poles (download and use this spreadsheet model (.zip) to understand it) never falls below the value of Distance Dmin as shown (in green color) in Position 0. If it however does, then it becomes necessary to add KryonGates that are rotationally offset, i.e. by 90 degrees, as shown in Example 2.

The Linear KryonGate: A mechanical concept

The 5 key positions of the KryonGate shown above may be implemented by assembling a build of a Linear KryonGate as shown below (top view & side view). Recommendation: Extend this concept to represent a full section of the Example 2 (using the "x configuration").

How it works

Magnet [1] (mounted onto the Lead screw nut [2]) is magnetically attracted to Magnets [3] and [4], thereby gliding towards them, guided by the High-helix lead screw [5] and the Linear shafts [6] and [7].

The linear movement of the Magnet [1] along the High-helix lead screw [5] induces a rotation on the Lead screw nut [2] and the Magnet [1] which is then transmitted to

  • the Linear shafts [6] and [7],
  • the Cogwheels [8], [9], [10], [14],
  • the Linear shafts [11] and [15],
  • the Magnets [3] and [4],
  • the Cogwheels [12] and [13], and
  • the High-helix lead screw [5],

thereby adding an additional rotation to the latter, which further increases the distance of the linear movement covered by the Magnet [1].

Constraints and important details

  • The High-helix lead screw [5] rotates freely inside the Cogwheels [8] and [9] (the latter are exceptionally not mounted onto the former).
  • Cogwheel [9] has precisely half the diameter of Cogwheel [10] or [14].
  • Cogwheels [10] and [14] have identical diameters.
  • Cogwheels [12] and [13] can be easily removed and replaced by various sets of Cogwheels with differing diameter combinations. This allows the engineer to increase or decrease the resulting total linear movement covered by the Magnet [1], which is useful to flexibly determine the optimal distances/proportions/trajectories.
  • The proportions and distances between the 5 key positions in an actual build must be chosen such that - throughout the entire movement - the spatial Distance D between the attracting (respectively repulsing) magnetic poles never falls below the value of Distance Dmin as shown (in green color) in Position 0. The distance between Position -2 and Position 0 (respectively between Position 0 and Position +2) should thus be maximized.
  • Use NdFeB magnets (the strongest kind) to bridge this maximized distance, but handle them with extreme caution to avoid physical injury!

How to calibrate and use the device

  • Remove one of the Cogwheels [12] and [13].
  • Bring the Magnets [1], [3] and [4] precisely into the "Position 0" (center position).
  • Mount the previously removed Cogwheel [12] or [13].
  • Manually move Magnet [1] into the "Position -2" (start position) and release it to observe the resulting movement.
  • Replace the Cogwheels [12] and [13] by different sets of Cogwheels with varying combinations of diameters in order to determine the optimal coordinates of the "Position -2" (start position) and thus the total distance of the linear movement covered by the Magnet [1].

Potential disadvantages of this design

  • The poles of the Magnet [1] in this particular design can only describe a regular double-helix movement, not an irregular one (which may be optimal or necessary, and could be induced by one or two guiding rails).

FAQ

  • What can KryonEngines be used for?

    KryonEngines can power buildings (homes, offices, factories, etc.), means of transport (cars, buses, boats, airplanes, etc.), electronic devices (computers, TVs, in miniaturized form: mobile phones, etc.), and much more - at almost no cost (other than the cost of the initial acquisition and rare maintenance).

  • What do KryonEngines do for our health, environment and consciousness?

    KryonEngines offer independence from antiquated, polluting and illness-inducing energy sources, such as nuclear energy (production of hazardous nuclear waste, currently still ongoing leakage of radiating material at contaminated sites such as Chernobyl, Fukushima, etc.), fossil fuels such as petroleum (air pollution from petroleum-fueled vehicles, engines, and industrial processes, as well as oil spills from tankers, pipelines, and oil wells into land and marine ecosystems, releasing toxins dangerous to humans and many organisms), coal (production of soot, smog, acid rain, and waste such as sludge, toxic chemicals, etc.) and natural gas (leakage of methane, groundwater near gas wells contaminated with gases and fracking fluids, etc.) and thus contribute to a clean environment promoting health, abundance and a higher consciousness in the global population.

  • How can I amplify the output obtained by a KryonEngine?

    KryonEngines become powerful independent energy generators when a KryonEngine using permanent magnets is used to power a KryonEngine using electromagnets.

  • What do KryonEngines mean for the future of energy grids?

    KryonEngines offer energy grid independence (which is crucial for the well-being of the population of the United States of America and many other countries currently lacking the necessary infrastructure investments).

  • What do KryonEngines mean for the future of batteries?

    KryonEngines offer independence from batteries themselves as well as from their toxic components and their explosion/fire hazard.

  • How do you handle the energy that is produced by KryonEngines 24hrs per day, 365 days per year, when you are not using it?

    Push it to a supercapacitor (also called "ultracapacitor") for later use.

  • How are KryonEngines serviced?

    KryonEngines maintenance mainly consists of regular greasing and the replacement of heavily used bearings.

  • What are my rights regarding the information presented about the KryonEngine?

    The KryonEngine and the KryonGate have been put intentionally and FULLY IN THE PUBLIC DOMAIN, REPRESENT 'PRIOR ART' AND CAN THEREFOR NOT BE PATENTED. Any patent attempting to make any of the presented information, ideas or concepts proprietary can be invalidated immediately and in any country.
    The information presented has aditionally been submitted to the IP.com Prior Art Database; as such it has been notarized and has received a legally valid publication timestamp. It has thus been made readily available to all patent examiners worldwide.
    You have the right to use the presented information fully, commercially and without any limitation whatsoever.

  • Why have you open-sourced the KryonEngine instead of registering patents worldwide and selling them for hundreds of billions?

    Patents can be used to fully block the improvement, the propagation, the use and the resulting benefit and abundance of important innovations for The People.
    They can also be used for the aim of enriching oneself massively by monopolizing important inventions and thereby limiting the improvement, the propagation, the use and the resulting benefit and abundance for The People.
    The Open-source movement works for The People. It maximizes the improvement, the propagation, the use and the resulting benefit and abundance for The People. It limits the power of service-to-self factions and supports those being of service-to-others. It is therefor fully aligned with the future of Humanity.

  • What does Kryon mean?

    The correct question would be: Who is Kryon? Kryon supports Humanity in many precious ways - not only by dropping hints about upcoming revolutionary technologies based on magnetism, such as (shallow depth) geothermal energy generation, (mass-scale) water desalination and magnetic engines. You are encouraged to tune in to the neverending stream of new free audio channellings. Also be sure to read Lee Carroll's answer to this question.



Namaste,

Thomas Hardtmuth, on 9/11 2021
(Switzerland)
